README.md

led-bar

Install Pipenv

https://pipenv.pypa.io/en/latest/installation.html

Download dependencies

pipenv sync

Install Micropython

https://micropython.org/resources/firmware/ESP32_GENERIC_C3-20241129-v1.24.1.bin

pipenv run esptool.py --port PORTNAME erase_flash
pipenv run esptool.py --port PORTNAME --baud 460800 write_flash 0 ESP32_GENERIC_C3-20241129-v1.24.1.bin

Upload libraries and src

pipenv run ./dev.py PORTNAME lib src

Upload src, reset and follow

pipenv run ./dev.py PORTNAME src reset follow

Connect

Connect to wifi nextwork called led-xxxxxx...

http://192.168.4.1/
