- Process 't' field to distinguish between beat ('b') and update ('u') messages
- Beat messages: execute pattern immediately using current parameters
- Update messages: only update parameters, don't execute pattern
- Maintains backward compatibility with default to beat if 't' not specified
- Enables proper synchronization between controller and bars
led-bar
Install Pipenv
https://pipenv.pypa.io/en/latest/installation.html
Download dependencies
pipenv sync
Install Micropython
https://micropython.org/resources/firmware/ESP32_GENERIC_C3-20241129-v1.24.1.bin
pipenv run esptool.py --port PORTNAME erase_flash
pipenv run esptool.py --port PORTNAME --baud 460800 write_flash 0 ESP32_GENERIC_C3-20241129-v1.24.1.bin
Upload libraries and src
pipenv run ./dev.py PORTNAME lib src
Upload src, reset and follow
pipenv run ./dev.py PORTNAME src reset follow
Connect
Connect to wifi nextwork called led-xxxxxx...
